Introduction

In an effort to improve the quality of cake roasting, a control device has been designed for a cake grill that utilizes the ATmega328 Microcontroller and K Type thermocouple. This tool is designed to overcome various problems that are often faced by household scale bread entrepreneurs, such as inconsistent roasting temperatures, pollution potential, and doubts about food hygiene that may be polluted by fuel. Through this article, we will explain this semi-automatic oven model, which is equipped with temperature settings and roasting time.

Description of the Tools and Their Functions

The developed oven model includes hardware and microcontroller-based software. Thermocouple sensor serves to monitor temperatures with high accuracy. In this system, MAX6675 is used to strengthen the signal from thermocouple so that it can be read by LCD. The ATmega328 microcontroller is the control center that regulates the temperature and displays the measurement results on the LCD screen.

The roasting time regulator is also integrated in this system. By using MAX6675 as a source of time, the ATmega328 microcontroller can control the duration of the oven heating, so that the roasting process can be done more precisely and efficiently.

The Advantages and Benefits of Using Thermocouple Type K

The use of the K thermocouple type in this oven offers a number of advantages. Firstly, the ability to produce more accurate temperature reading allows bread entrepreneurs to maintain the consistency of their products. This is very important in the food industry, where the quality of the product is very dependent on the proper roasting process.

Secondly, with a good temperature control system, the risk of pollution due to fuel combustion can be minimized. This not only helps in maintaining food quality, but also guarantees safety for consumers.

Furthermore, this device also plays an important role in increasing the efficiency of the production process. With precision roasting time settings, bread entrepreneurs can maximize their production output without sacrificing quality.

Trial Results and Implementation

After going through a series of testing, this tool is proven to work well in controlling the temperature and time of roasting. The trial results show that this system can maintain temperatures at the desired level, as well as regulate the work time of the oven heater. This is an indication that this tool can be implemented effectively in the household scale bread industry.

The Working Principle of the System

The system works on the principle of thermocouple type K, which is a type of temperature sensor that produces a small voltage output proportional to the temperature difference between the two junctions. The MAX6675 IC is used to amplify this voltage output and convert it into a digital signal that can be read by the ATmega328 microcontroller.

The ATmega328 microcontroller then uses this digital signal to control the temperature and time of roasting. The system also includes a LCD display that shows the temperature and time of roasting.

The Advantages of Using ATmega328 Microcontroller

The use of ATmega328 microcontroller in this system offers a number of advantages. Firstly, it provides a high level of accuracy and precision in temperature control. Secondly, it is a low-power microcontroller that can be powered by a single battery, making it ideal for use in a cake grill oven.

Thirdly, it has a large number of I/O pins that can be used to connect various sensors and actuators, making it a versatile microcontroller that can be used in a wide range of applications.

Conclusion

With the application of thermocouple technology type K and ATmega328 microcontroller, this cake grill oven offers an innovative solution for bread entrepreneurs. This tool not only improves the quality of roasting, but also guarantees safety and efficiency in the production process. Thus, the development of this technology has the potential to increase the competitiveness of the food industry, especially on a home scale.

Future Scope

The use of thermocouple type K and ATmega328 microcontroller in a cake grill oven has a wide range of applications in the food industry. Future scope of this technology includes the development of more advanced temperature control systems that can be used in a wide range of applications, including industrial baking and cooking.

Additionally, the use of this technology can also be extended to other areas, such as temperature control in laboratories and industrial processes. The development of this technology has the potential to revolutionize the food industry and make it more efficient and productive.

References

[1] "Thermocouple Type K" by Wikipedia
[2] "ATmega328 Microcontroller" by Microchip
[3] "MAX6675 IC" by Maxim Integrated
