Introduction

In the world of electrical engineering, especially in the electric power system, dynamic stability is an important factor that determines the reliability of the system. One way to increase this stability is to use the Power System Stabilizer (PSS). This final project aims to analyze how PSS installation can improve dynamic stability in the multimesin electric power system consisting of three generators. Dynamic stability is crucial in ensuring that the power system can maintain its balance and operate efficiently, even in the presence of disturbances or changes in load.

Mathematical Modeling of the Electric Power System

The model used in this analysis begins by creating a mathematical representation of an electric power system without a power stabilizer power system. In this stage, the equation of the state variable is developed and formed into a diagram block that reflects the system plant. The input in this model comes from changes in rotor speed, while the output of PSS will enter the excitation. This mathematical representation is essential in understanding the behavior of the power system and how PSS can improve its stability.

Analysis of PSS Installation

This study shows that the ability of electric power systems equipped with PSS to reduce oscillations is far better than systems without PSS. This is important because unpiled oscillations can be fatal, ranging from decreased efficiency to damage to equipment. With PSS, the oscillation that arises due to interference can be minimized, so that the stability of the system is maintained. PSS installation not only adds new components in the system, but also increases the interaction between the generator and the load.

Dynamic Stability Analysis

In the development of mathematical models, the electric power system is formulated in the form of linear differential equations. Furthermore, the application of PSS on the generation side was analyzed using a dynamic stability analysis method. By inserting PSS into excitation input, the system can respond to the disorder more stable, which means the ability to maintain its performance in fluctuations. This analysis is crucial in understanding how PSS can improve the dynamic stability of the power system.

Implications of PSS Installation

PSS installation can contribute to reducing maintenance costs. A more stable system tends to experience less disturbance and failure, which in turn will reduce the frequency and cost of maintenance. This is a added value for electric power system operators in achieving operational efficiency. In addition, the existence of PSS can ensure a reliable and efficient electricity supply to consumers.

Technological Development and PSS

In the context of technological development, the use of PSS is increasingly relevant, especially with increasing dependence on renewable energy sources that have fluctuating characteristics. With good PSS implementation, electric power systems can more easily adapt and operate optimally in the middle of the dynamics that occur. This is essential in ensuring that the power system can maintain its stability and reliability in the face of changing load and generation patterns.

Conclusion

Overall, the use of power system stabilizer in the multimesin electric power system has proven to be effective in improving dynamic stability. By analyzing and building the right mathematical model, as well as paying attention to interactions in the system, PSS can be an ideal solution to improve the performance and efficiency of the electric power system. In facing future challenges, such as renewable energy integration, the existence of PSS will be increasingly important in maintaining the stability and reliability of the electric power system.

Recommendations

Based on the analysis and implications of PSS installation, the following recommendations can be made:

Electric power system operators should consider installing PSS in their systems to improve dynamic stability and reduce maintenance costs.
Engineers should pay attention to the interaction between the generator and the load when designing systems with PSS.
The use of PSS should be considered in the context of technological development, especially with increasing dependence on renewable energy sources.

Future Research Directions

Future research directions in this area could include:

Investigating the impact of PSS on the stability of power systems with high penetration of renewable energy sources.
Developing more advanced mathematical models to analyze the behavior of power systems with PSS.
Exploring the use of PSS in other applications, such as in the transmission and distribution of electricity.

By following these recommendations and exploring future research directions, the use of PSS can continue to improve the dynamic stability and reliability of electric power systems.
