In engineering, pulley systems are widely used to transmit power and motion between two or more points. A pulley system consists of a driving pulley and a driven pulley, connected by a belt or rope. The speed of the driven pulley is directly related to the speed of the driving pulley and the ratio of their diameters. In this article, we will explore how to calculate the resulting rpm of the driven pulley when the diameter of the motor pulley is decreased.

The Importance of Speed Ratios in Pulley Systems

The speed ratio of a pulley system is determined by the ratio of the diameters of the driving and driven pulleys. When the diameter of the driving pulley is increased, the speed of the driven pulley decreases, and vice versa. This is because the circumference of the pulley is directly proportional to its diameter. As the diameter of the driving pulley increases, the circumference also increases, resulting in a decrease in the speed of the driven pulley.

Calculating the Speed Ratio

The speed ratio of a pulley system can be calculated using the following formula:

Speed Ratio = (Diameter of Driving Pulley) / (Diameter of Driven Pulley)

For example, if the diameter of the driving pulley is 6" and the diameter of the driven pulley is 18", the speed ratio would be:

Speed Ratio = 6" / 18" = 1/3

This means that the speed of the driven pulley is 1/3 of the speed of the driving pulley.

Applying the Speed Ratio to the Given Problem

In the given problem, the diameter of the motor pulley is decreased from 6" to 4", while maintaining a speed of 1800 rpm. We need to calculate the resulting rpm of the driven pulley with an 18" diameter.

First, we need to calculate the speed ratio of the new pulley system:

Speed Ratio = (Diameter of Driving Pulley) / (Diameter of Driven Pulley) = 4" / 18" = 2/9

Since the speed of the driving pulley is 1800 rpm, we can calculate the speed of the driven pulley using the speed ratio:

Speed of Driven Pulley = Speed of Driving Pulley x Speed Ratio = 1800 rpm x (2/9) = 400 rpm

Therefore, the resulting rpm of the driven pulley with an 18" diameter is 400 rpm.

Conclusion

In conclusion, the speed of the driven pulley in a pulley system is directly related to the speed of the driving pulley and the ratio of their diameters. By understanding the basics of pulley systems and speed ratios, engineers can design and optimize pulley systems to meet specific requirements. In this article, we have demonstrated how to calculate the resulting rpm of the driven pulley when the diameter of the motor pulley is decreased.

References

[1] "Pulley Systems" by Wikipedia
[2] "Mechanical Advantage" by Engineering Toolbox
[3] "Pulleys and Gears" by NASA

Frequently Asked Questions

Q: What is the speed ratio of a pulley system? A: The speed ratio of a pulley system is determined by the ratio of the diameters of the driving and driven pulleys.
Q: How do I calculate the speed ratio of a pulley system? A: You can calculate the speed ratio using the formula: Speed Ratio = (Diameter of Driving Pulley) / (Diameter of Driven Pulley)
Q: What is the resulting rpm of the driven pulley with an 18" diameter when the diameter of the motor pulley is decreased from 6" to 4"? A: The resulting rpm of the driven pulley with an 18" diameter is 400 rpm.
